more info more info MoxiE Ultra High Current Power Inductors Minim velit, ex velit culpa sed sint ad fugiat, MOX-SPI-1610 SERIES 4.45mm x 4.05mm x 1.00mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~10.0uH Isat Max: 25.0 Amps MOX-SPI-2040S SERIES 4.45mm x 4.05mm x 2.00mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~4.70uH Isat Max: 33.0 Amps MOX-SPI-2525R SERIES 7.20mm x 6.65mm x 3.00mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.47uH~22.0uH Isat Max: 21.0 Amps MOX-SPI-2525 SERIES 6.80mm x 6.50mm x 3.00mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~10.0uH Isat Max: 61.0 Amps MOX-SPI-2525A SERIES 7.00mm x 6.47mm x 1.80mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~4.70uH Isat Max: 40.0 Amps MOX-SPI-2525B SERIES 7.00mm x 6.47mm x 2.40mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~10.0uH Isat Max: 50.0 Amps MOX-SPI-2525V SERIES 7.40mm x 6.65mm x 5.00mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.56uH~2.20uH Isat Max: 20.0 Amps MOX-SPI-4020 SERIES 4.00mm x 4.50mm x 2.00mm Low Profile, High Current Temp Range: -55C~105C Low Power Loss & DCR Inductance: 0.10uH~3.30uH Isat Max: 32.0 Amps MOX-SPI-4040D SERIES 11.5mm x 10.0mm x 4.00mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.36uH~10.0uH Isat Max: 61.0 Amps MOX-SPI-5050 SERIES 13.6mm x 12.9mm x 3.50mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~10.0uH Isat Max: 81.0 Amps MOX-SPI-5050E SERIES 13.6mm x 12.9mm x 5.00mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~10.0uH Isat Max: 118.0 Amps MOX-SPI-5050F SERIES 13.6mm x 12.9mm x 6.50mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~10.0uH Isat Max: 120.0 Amps MOX-SPI-5050L SERIES 13.6mm x 12.9mm x 3.50mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~10.0uH Isat Max: 80.0 Amps MOX-SPHC-1405 SERIES 13.9mm x 13.5mm x 5.20mm Molded Power Inductor Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~10.0uH Imax: 65.0 Amps MOX-SPHC-1403 SERIES 13.9mm x 13.5mm x 3.70mm Molded Power Inductor Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~10.0uH Imax: 44.0 Amps MOX-SPHC-1305 SERIES 13.2mm x 12.9mm x 5.00mm Low Profile, High Current Temp Range: -55C~125C Low Power Loss & DCR Inductance: 0.10uH~10.0uH Imax: 118.0 Amps MOX-API-0705 SERIES 6.8mm x 6.8mm x 9.0mm High Current Metal Alloy Temp Range: -55C~105C Low Copper Loss Design Inductance: 0.27uH~1.60uH Isat Max: 37.0 Amps MOX-API-0805 SERIES 8.3mm x 8.3mm x 10.0mm High Current Metal Alloy Temp Range: -55C~105C Low Copper Loss Design Inductance: 0.80uH~3.00uH Isat Max: 28.0 Amps MOX-API-1005 SERIES 10.5mm x 10.5mm x 9.5mm High Current Metal Alloy Temp Range: -55C~105C Low Copper Loss Design Inductance: 0.30uH~1.80uH Isat Max: 45.0 Amps MOX-API-1105 SERIES 11.5mm x 11.5mm x 9.5mm High Current Metal Alloy Temp Range: -55C~105C Low Copper Loss Design Inductance: 0.30uH~4.70uH Isat Max: 55.0 Amps MOX-API-1205 SERIES 12mm x 12mm x 10mm High Current Metal Alloy Temp Range: -55C~105C Low Copper Loss Design Inductance: 0.30uH~2.00uH Isat Max: 65.0 Amps MOX-API-1305 SERIES 13.5mm x 12.5mm x 10.5mm High Current Metal Alloy Temp Range: -55C~105C Low Copper Loss Design Inductance: 0.30uH~2.00uH Isat Max: 70.0 Amps MOX-API-1405 SERIES 14mm x 14mm x 12.5mm High Current Metal Alloy Temp Range: -55C~105C Low Copper Loss Design Inductance: 0.30uH~2.00uH Isat Max: 80.0 Amps MOX-API-1605 SERIES 16.5mm x 16.5mm x 13.5mm High Current Metal Alloy Temp Range: -55C~105C Low Copper Loss Design Inductance: 0.30uH~2.00uH Isat Max: 100.0 Amps MOX-DAI-0910 SERIES 9mm x 10mm x 10.5mm Digital Amplifier Inductor Temp Range: -40C~85C Low Radiation & Noise Inductance: 6.80uH~22.00uH Isat Max: 7.85 Amps MOX-DAI-1310 SERIES 10mm x 10.5mm x 13mm Digital Amplifier Inductor Temp Range: -40C~85C Low Radiation & Noise Inductance: 6.80uH~22.00uH Isat Max: 11.00 Amps MOX-DAI-6511 SERIES 11mm x 6.5mm x 10.5mm Digital Amplifier Inductor Temp Range: -40C~85C Low Radiation & Noise Inductance: 6.80uH~22.00uH Isat Max: 7.80 Amps MOX-DAI-1912 SERIES 12mm x 11.5mm x 19mm Digital Amplifier Inductor Temp Range: -40C~85C Low Radiation & Noise Inductance: 10uH~22.00uH Isat Max: 8.00 Amps MOX-HPC-6630 SERIES 6.65mm x 6.45mm x 3.00mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 0.18uH~3.30uH Isat Max: 39.00 Amps MOX-HPC-8878 SERIES 8.80mm x 8.30mm x 7.80mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 0.68uH~10.00uH Isat Max: 38.00 Amps MOX-HPC-1188 SERIES 11.6mm x 10.5mm x 8.80mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 2.20uH~15.00uH Isat Max: 32.00 Amps MOX-HPC-1610 SERIES 16.4mm x 15.4mm x 10.0mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 4.70uH~22.00uH Isat Max: 47.00 Amps MOX-HCPI-2623 SERIES 26.9mm x 16.9mm x 23.2mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 3.30uH~33.0uH Isat Max: 105.00 Amps MOX-HCPI-2014 SERIES 20.5mm x 14.0mm x 12.0mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 0.50uH~33.00uH Isat Max: 75.00 Amps MOX-HCPI-2015 SERIES 20.5mm x 14.0mm x 14.5mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 2.20uH~33.00uH Isat Max: 60.50Amps MOX-HCPI-2815 SERIES 27.9mm x 19.7mm x 15.4mm Flat Wire High Current Magnetically Shielded Design Temp Range: -40C~125C Inductance: 1.50uH~33.00uH Isat Max: 100.00 Amps
